Technical Data
|
|
Jacket, diameter
|
PVC 4.2 mm
|
|
AWG
|
26
|
|
No. of inner conductors
|
2 x 0.14 mm²
|
|
Copper strand per conductor
|
18 x 0.10 mm
|
|
Conductor insulation
|
LLDPE
|
|
Shielding
|
Braided shielding
with 96 x 0.10mm
|
|
Shielding factor
|
85 %
|
|
Temperature range
|
min. -20 °C
|
|
Temperature range
|
max. +70 °C
|
|
Packaging
|
100/200 m roll
|
Electrical Data
|
|
Capac. cond./cond. per 1 m
|
52 pF
|
|
Capac. cond./shield. per 1 m
|
108 pF
|
|
Cond. resistance per 1 m
|
122 mΩ
|
|
Shield. resistance per 1 m
|
24.8 mΩ
|
Features
• Ideal for patch cables owing to its small outside diameter
• Thin jacket, suitable for the internal wiring, save more space
• High quality and flexibility, well-suited for use with mini XLR
• Use special LLDPE for the insulation, ensure a good electrical performance and tensile strength
Applications
• Professional studio patch connection
• Interior rack wiring and connection of audio components and effects devices
• Long-distance MIDI cabling
• High-quality mini XLR microphone cable
